74LCX125MX

low voltage quad buffer, 7.0 V, 100 mA, 25.0 pF, 14SOIC

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.22~0.25 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 100 :	0.25 / Piece
101 ~ 500 :	0.23 / Piece
501 ~ 1000 :	0.22 / Piece

PartNumber:: 74LCX125MX

Brand:: Fairchild Semiconductor - Fairchild | Pack: SOIC | D/C: 11+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Datasheet:: 74LCX125MX Datasheet download

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. cindy's store

(China (Mainland))

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-01-06

From Other Seller

Part Number:74LCX125MX
US $0.22 - 0.25
Quantity:

piece

Product Summary

The 74LCX125MX is a low voltage quad buffer with 5V tolerant inputs and outputs. The 74LCX125MX contains four independent non-inverting buffers with 3-STATE outputs. The inputs tolerate voltages up to 7V allowing the interface of 5V systems to 3V systems. The 774LCX125MX is fabricated with an advanced CMOS technology to achieve high speed operation while maintaining CMOS low power dissipation.

Parametrics

74LCX125MX absolute maximum ratings: (1)VCC Supply Voltage: -0.5 to 7.0 V; (2)VI DC Input Voltage: -0.5 to 7.0 V; (3)VO DC Output Voltage -0.5 to 7.0: Output in 3-STATE V; (4)-0.5 to VCC 0.5: Output in HIGH or LOW State V; (5)IO DC Output Source/Sink Current: 50 mA; (6)ICC DC Supply Current per Supply Pin: 100 mA; (7)IGND DC Ground Current per Ground Pin: 100 mA; (8)TSTG Storage Temperature: -65 to 150°C; (9)CPD Power Dissipation Capacitance VCC 3.3V, VI 0V or VCC, f 10 MHz: 25.0 pF.

Features

74LCX125MX features: (1)5V tolerant inputs and outputs; (2)2.3V–3.6V VCC specifications provided; (3)6.0 ns tPD max (VCC 3.3V), 10 PA ICC max; (4)Power down high impedance inputs and outputs; (5)Supports live insertion/withdrawal (Note 1); (6)r24 mA output drive (VCC 3.0V); (7)Implements patented noise/EMI reduction circuitry; (8)Latch-up performance exceeds JEDEC 78 conditions; (9)ESD performance: Human body model 2000V, Machine model 100V; (10)Leadless Pb-Free DQFN packa.
